Description
The Automatic External Defibrillator AED7000 is a defibrillation device, which is safe, portable and easy to use. It can be applied in a family and public place to give first aid for the symptom of sudden death. Combined with the advanced ECG analytical technique from M&B, the defibrillator can analyze the patient’s ECG, make a judgment on the patient’s cardiac monitor and indicate whether it is defibrillation, but also minimize injuries of heart defibrillation. The defibrillator will guide the operator to perform the defibrillation treatment via a voice prompt step by step, will give a security alert if the opportunity arises.
Automatic External Defibrillator AED7000 Features:
- Three-step defibrillation process with two-button operation
- Extensive voice and visual prompts for the operator
- Continuous event recording for reporting each use to a printer or computer
- Weekly self-test to ensure readiness
- Biphasic energy output
- Lock-out protection to prevent inadvertent defibrillation
![AED-7000 Automated External Defibrillator--Operation Video](https://i.ytimg.com/vi/cEfbOhPa7FQ/hqdefault.jpg)
Automatic External Defibrillator AED7000 Specifications:
Attribute | Value |
---|---|
Output | Biphasic Truncated exponential |
Energy Sequence | 150J, 150J, 200J |
Charge Time | 8 sec. to 150J 10 sec. to 200J (NEW battery) |
Analysis Time | 9 sec. |
Maximum Time from Initiation to Readiness (New Battery) | Less than 30 seconds |
Maximum Time from Initiation to Readiness (After 6 Shocks) | Less than 35 seconds |
Maximum Time from Initiation to Readiness | Less than 25 seconds |
Audible Prompts | 20 audible prompts |
Visual Prompts | LED prompts |
Controls | Two buttons – On/Off, Shock |
Output Energy Accuracy | ±15% into impedance from 25 to 75Ω |
Maximum Voltage | 1200±50V |
Output Disabled When Patient Impedance is Outside Limits | 20Ω to 200Ω |
